Separating substances at medium rotational speeds: IKA G-L is the ideal midi centrifuge for all types of separation processes such as those found in molecular biology. It can be used with standard 1.5/2 ml vessels, as well as with PCR strips. The cover opens automatically at the press of a button.
Safe use
The centrifuge is fitted with a metal cover and does not start until it is firmly closed.
State-of-the-art display
The completely intuitive navigation is carried out through a membrane keypad. This allows an easy setting of speed, rotational speed or programmes.
Powerful motor
With a rotational speed of up to 15,700 rpm, the centrifuge is fitted with a high-performance motor.
Broad scope of delivery
Metal rotor and cover for 12 vessels, with a capacity of 1.5/2 ml, are already included in the scope of delivery.
|
Capacity |
12 x 1.5/2.0 ml |
|
Pemitted density |
1.2 kg/dm3 |
|
Centrifugal acceleration |
16500 G |
|
Motor rating input |
65 W |
|
Speed range |
800 - 15700 rpm |
|
Speed deviation |
5 % |
|
Setting accuracy speed |
100 ±rpm |
|
Timer |
yes |
|
Timer display |
7 segment LED |
|
Unbalance sensor |
yes |
|
Quick stop |
yes |
|
Cover opening |
automatic |
|
Rotor exchange |
without tool |
|
Protective cover |
yes |
|
Dimensions (W x H x D) |
200 x 140 x 280 mm |
|
Weight |
3.9 kg |
|
Permissible ambient temperature |
+5 - +40 °C |
|
Permissible relative humidity |
80 % |
|
Protection class according to DIN EN 60529 |
IP 20 |
|
USB interface |
yes |
|
Voltage |
220 - 230 / 115 / 100 V |
|
Frequency |
50/60 Hz |
|
Power input |
92 W |
|
Power input standby |
18 W |
